BE-FLOW CUSTOM (10 devices per box)

BE-Flow: is our most easy-to-use device dedicated to cell culture under flow. It allows the performance of long term 2D or 3D culture in two independent channels. BE-Flow is compatible with any microfluidic pump system and can be used simply with a rocker, thanks to its fluid reservoirs situated by the inlets/outlets. This is an optimal device for vascular research where shear stress plays a major role in gene expression.

*Without  taxes
Does your application need for specific shear stress, flux and pressure values?
Channel width 1.1 – 5.7 mm

Channel height: 0.2 – 1 mm

Select de optimal shape of the microchannels to recreate the perfect physiological environment in terms of shear stress, flux and pressure inside the chip.

Do you use functionalized or micropatterned surfaces, or even sensors in your culture?
Options: Plastic base, custom base.

Acquire the BE-Flow system with a biocompatible adhesive instead of the plastic base and glue it on a biocompatible plastic or glass surface prepared for you application (micropatterned surfaces, lithographed sensors or electric stimulation systems). For more information contact us at info@beonchip.com.

Clear

Culture Models

Perform 2D culture experiments under flow controlling the mechanical shear stress on the cells in two independent channels.

Be-Flow device allows 2D culture on all the walls of the device: top, bottom, … (see technical note). Co-culture with two different cell types monolayer is also possible

Investigate the effect of circulating particles such as circulating tumor cells, immune system cells, bacteria, fungi, viruses and many more in a 2D culture.



Applications

BE-Flow is the ideal device to initiate a research in the effect of flow and mechanical stress on a cell culture. Some of most common applications are mechanical shear stress studies, interstitial flow on 3D cultures, rolling and adhesion or circulating particle experiments.

Vascular research: BE-flow has been designed for vascular research. Therefore, some of the most common applications of the BE-Flow device are related to this field of knowledge. Endothelial vascular cells as HUVEC or HAEC are influenced by several forces in the human body due to the blood flow. Using the BE-Flow it is possible to control precisely shear stress and transmural pressure at the same time. These forces play an important role in the gene expression of HUVEC cells and their proper development. In addition, these forces can be modified to a disease level to study phenomena such as thrombosis, atherosclerosis or rolling adhesion of circulating particles in the endothelial tissue.

See moore

Device features

  • Easy to use: Be-Flow is compatible with any type of optical microscopy (confocal, fluorescence…) and its slide format has been chosen for easy handling under a microscope.
  • Easy to connect: Be-Flow is compatible with all microfluidic flow control systems (syringe, peristaltic pumps, pressure control systems, rocker systems…).
  • No unspecific absorption: Unlike in other PDMS devices, Be-Flow is made of lipophobic thermoplastic materials and does not present unspecific drug absorption issues.It allows inmunohistochemistry with fluorescent detection.
  • Impermeability: These materials have a very low permeability to oxygen and water vapor, allowing precise control of those gases inside the microchannel by controlling their concentration in the culture medium and its flux.
  • Cell recovery option: The cell cultures used in the Be-Flow can be easily recover for further experimentation.

How to video

Organ on a Chip technology consists on microfluidic cell culture chips that try to reproduce different physiological responses of organs on a lab.
